Outplay V8 (T) Mk2

Add to Wishlist
Add to Wishlist
In stock

1×8″ 2-way Loudspeaker System

Add to Wishlist
Add to Wishlist

The OUTPLAY V8 is a long throw, compact loudspeaker designed for a variety of install applications. Employing an incredibly low-distortion 8″ coaxial-driver, the V8 will surprise you with its performance. The OUTPLAY V8 body is made of engineering plastic injection moulding and conforms to IP56 international standard.V8T is equipped with multi-tap transformer based on V8.

Compact cabinet design allows the system to be used for various installations where compact size is important without compromising on quality and power. The V8 is an ideal solution for installations of individual speakers in halls or clusters in cultural or religious venues.

Features:

  • Two-Way High-Output Full-range
  • High SPL
  • Horn loaded design for coaxial components
  • Compact multipurpose Design
  • Highly weather-resistant IP56 rating
  • Engineering plastic injection moulding
  • Ip 55, Waterproof speakers

Applications:

  • individual speakers in halls
  • or clusters in cultural or religious venues

Technical Specification

MODEL V8(T)MK2
FREQUENCY RESPONSE(-3dB) 80Hz-18kHz
FREQUENCY RESPONSE(-10dB) 75Hz-20kHz
DRIVERS 1×8″(200mm)/2″ voice coil LF
1×1″(25mm)/1.4″voice coil HF
INPUT VOLTAGE 100V Line Transformer
RATED POWER 37.5W/75W/150W/OFF/8Ω
SENSITIVITY 96dB 1watt/1 metre
MAXIMUM SPL 117dB continuous,123dB peak
IMPEDANCE 8 ohms nominal
DISPERSION(-6dB) 100°×100°
CROSSOVER FREQUENCIES 2.5kHz passive
INPUT CONNECTORS covered barrier strip terminals
PACKAGE SIZE 410mm×368mm×377mm
NET WEIGHT 11 kg/pc
GROSS WEIGHT 13 kg/pc
