Outplay V12 (T) Mk2

Add to Wishlist
Add to Wishlist
In stock

1×12″ 2-way Loudspeaker System

Add to Wishlist
Add to Wishlist

The OUTPLAY V12 is a long throw, compact loudspeaker designed for a variety of install applications. Employing an incredibly low-distortion 12″ coaxial-driver, the V12 will surprise you with its performance. The OUTPLAY V12 body is made of engineering plastic injection moulding and conforms to IP56 international standard. V12T is equipped with multi-tap transformer based on V12.

Compact cabinet design allows the system to be used for various installations where compact size is important without compromising on quality and power. The V12 is an ideal solution for installations of individual speakers in halls or clusters in cultural or religious venues.

Features:

  • Two-Way High-Output Full-range
  • High SPL
  • Horn loaded design for coaxial components
  • Compact multipurpose Design
  • Highly weather-resistant IP56 rating
  • Engineering plastic injection moulding
  • Ip 55, Waterproof speakers

Applications:

  • sports facilities, stadiums, waterparks, outdoor background music, swimming pools
  • wide variety of other outdoor venue types
  • individual speakers in halls or clusters in cultural or religious venues

Technical Specification

MODEL V12(T) Mk2
FREQUENCY RESPONSE(-3dB) 55Hz-18kHz
FREQUENCY RESPONSE(-10dB) 50Hz-20kHz
DRIVERS 1×12″(300mm)/3″voice coil LF
1×1″(25mm)/1.7″voice coil HF
INPUT VOLTAGE 100v Line Transformer
RATED POWER 300W RMS,1200W peak
SENSITIVITY 98dB 1watt/1 metre
MAXIMUM SPL 122dB continuous,128dB peak
IMPEDANCE 8 ohms nominal
DISPERSION(-6dB) 80°×80°
CROSSOVER FREQUENCIES 2.2kHz passive
INPUT CONNECTORS covered barrier strip terminals
PACKAGE SIZE 518mm×495mm×505mm
NET WEIGHT 18 kg/pc
GROSS WEIGHT 20 kg/per piece
