OUTPLAY S8

Add to Wishlist
Add to Wishlist
In stock

1×8″ 2-way Loudspeaker System

• Two-Way High-Output Full-range
• 8-inch specialized woofer and 1-inch HF
• Advanced crossover with HF protection 150W continuous, 600W peak power handling
• Compact multipurpose Design
• Highly weather-resistant IP46 rating
• Engineering plastic injection moulding
• Two kinds of mounting brackets

Add to Wishlist
Add to Wishlist

The OUTPLAY S8 is weather-resistant, ultra-compact loudspeaker designed for a variety of install applications. Employing an incredibly low-distortion 8 inch woofer, the S8 will suprise you with its performance. A specially designed crossover network integrates
the speaker with a 1inchHF. The OUTPLAY S8 body is made of engineering plastic injection moulding and conforms to IP46 international
standard. S8T is equipped with multi-tap transformer based on S8.

Compact cabinet design allows the system to be used for various installations where compact size is important without compromising on quality and power. The S8 can be combined with OUTPLAY SB12 or SB8 for incredible full range sound. The S8 is an ideal solution for installations of individual speakers in conference halls, restaurants or clusters in cultural or religious venues

Applications

  • Bars / Bookstores/Café’s / Clothing Store
  • Fast Food Restaurants
  • variety of other outdoor or indoor background music
  • meeting rooms,
  • water parks, swimming pools,
  • wide variety of other outdoor or indoor background music

Technical Specification

MODEL S8B/S8W ES108BT/ES108WT
FREQUENCY RESPONSE(-3dB) 60Hz-18KHz 60Hz-18KHz
FREQUENCY RESPONSE(-10dB) 55Hz-20KHz 55Hz-20KHz
DRIVERS 1×8″(200mm)/2″voice coil LF 1×8″(200mm)/2″voice coil LF
1×1″(25mm)/1″voice coil HF 1×1″(25mm)/1″voice coil HF
INPUT VOLTAGE 100V
RATED POWER 150W RMS,600W peak 37.5W/75W/150W/OFF/16Ω
SENSITIVITY 94dB 1watt/1 metre 94dB 1watt/1 metre
MAXIMUM SPL 116dB continuous,122 dB peak 116dB continuous,122 dB peak
IMPEDANCE 16 ohms nominal 16 ohms nominal
DISPERSION(-6dB) 90°×50° 90°×50°
CROSSOVER FREQUENCIES 2.3kHz passive 2.3kHz passive
INPUT CONNECTORS covered barrier strip terminals covered barrier strip terminals
PACKAGE SIZE 370×310×525mm 370×310×525mm
NET WEIGHT 9 kg/pc 10 kg/pc
GROSS WEIGHT 11 kg/per piece 12 kg/pair
