OUTPLAY S6

Add to Wishlist
Add to Wishlist
In stock

1×6″ 2-way Loudspeaker System



  • Two-Way High-Output Full-range
  • 6-inch specialized woofer and 1-inch HF
  • Advanced crossover with HF protection
  • 80W continuous, 320W peak power handling
  • Compact multipurpose Design
  • Highly weather-resistant IP46 rating
  • Engineering plastic injection moulding



Add to Wishlist
Add to Wishlist

The OUTPLAY S6 is weather-resistant, ultra-compact loudspeaker designed for a variety of install applications. Employing an incredibly low-distortion 6 inch woofer, the S6 will suprise you with its performance. A specially designed crossover network integrates
the speaker with a 1inchHF. The OUTPLAY S6 body is made of engineering plastic injection moulding and conforms to IP46 international tandard.S6T is equipped with multi-tap transformer based on S6.

Compact cabinet design allows the system to be used for various installations where compact size is important without compromising on quality and power. The S6 can be combined with OUTPLAY SB8 or SB12 for incredible full range sound. The S6 is an ideal solution for installations of individual speakers in conference halls, restaurants or clusters in cultural or religious venues

Applications

  • Bars / Bookstores/Café’s / Clothing Store
  • Fast Food Restaurants
  • variety of other outdoor or indoor background music
  • meeting rooms,
  • water parks, swimming pools,
  • wide variety of other outdoor or indoor background music

Technical Specification

MODEL S6B/S6W ES106BT/ES106WT
FREQUENCY RESPONSE(-3dB) 60Hz-18KHz 60Hz-18KHz
FREQUENCY RESPONSE(-10dB) 55Hz-20KHz 55Hz-20KHz
DRIVERS 1×6″(150mm)/1.5″voice coil LF 1×6″(150mm)/1.5″voice coil LF
1×1″(25mm)/1″voice coil HF 1×1″(25mm)/1″voice coil HF
INPUT VOLTAGE 100V
RATED POWER 80W RMS,320W peak 20W/40W/80W/OFF/16Ω
SENSITIVITY 89dB 1watt/1 metre 89dB 1watt/1 metre
MAXIMUM SPL 110dB continuous,116 dB peak 110dB continuous,116 dB peak
IMPEDANCE 16 ohms nominal 16 ohms nominal
DISPERSION(-6dB) 90°×60° 90°×60°
CROSSOVER FREQUENCIES 2.4kHz passive 2.4kHz passive
INPUT CONNECTORS covered barrier strip terminals covered barrier strip terminals
PACKAGE SIZE 524×242×417mm(1 pair) 524×242×417mm(1 pair)
NET WEIGHT 5 kg/pc 6 kg/pc
GROSS WEIGHT 15 kg/pair 16 kg/pair
