Technical Specification
FREQUENCY RESPONSE(±3dB)：55Hz-20kHz
DRIVERS：81/4“/25mm voice coil LF & 25mm dome HF
RATED POWER：80W RMS, 100W peak
SENSITIVITY：90±3dB 1w/1m
MAXIMUMSPL：111 dB
IMPEDANCE：8 ohms nominal
DISPERSION 1kHz(-6dB)：Horizontal covrage: 100° & vertical coverage: 90°
CROSSOVER FREQUENCIES：2kHz passive
MATERIAL：ABS
COLOR：WHITE/BLACK
SIZE：241x339x195 (mm)
Grille Material：ALUMINIUM
Bracket Material：IRON
IP Level：IP66
INPUT CONNECTORS：4-position grid type terminal
NET WEIHT：5 kg/1pc
SIZE：241x339x195（mm）
